| Place of Origin: | China |
| Brand Name: | Ruijia |
| Certification: | CE |
Direct Manufacturer S Type Tension Pressure Load Cell 10 Ton Weighing Machine Load Cell for Hopper Scale
Features:
1. Available in capacities from 0 to 10 ton.
2. Alloy steel, sealed by adhesive inside, oil-proof, waterproof and anti-corrosion, suitable for all kinds of environments.
3. S beam design, tension and/or compression loading possible, easy installation, suitable for crane scale, mechanical conversion scale, hopper scale and other electronic weighing devices.
4. Provided with a certificate of conformance and full-scale calibration.
Description
S type load cells that receive tension or compression forces. Applications include tank weighing, hoppers, suspended loads and truck scales. S Type load cells provide superior performance in a compact, versatile package.
| Capacity | 0-2T 2-10T |
| Rated output | 2.0mV/V |
| Zero Balance | ±1%F.S. |
| Non-linearity | 0.05%F.S. |
| Hysteresis | 0.05%F.S. |
| Repeatability | 0.03%F.S. |
| Creep(30min) | 0.05%F.S. |
| Temp Effect on Output | 0.05% F.S. / 10ºC |
| Temp Effect on Zero | 0.05% F.S. / 10ºC |
| Maximum Overload | 200% |
| Operating Voltage Range | 5-15V |
| Operating Temp Range | -20~80 ºC |
| Safe overload | 150% |
| Cable Ultimate Pull | 10kg |
| Cable size | 0-2T:diameter 5X2m 2-10T:diameter 5X5m |
| Material | Alloy steel |
Company Information
Service standards: we are committed to provide a high quality and responsive service to all clients
The fastest reply: Please feel free to contact us if you have any questions. You will get a reply from the professional and experienced trade manager within 24 hours. If our trade manager is off line, please leave a message, and tell us the product model you need and your E-mail address.
Quality assurance: good quality is assured by advanced manufacturing technology. And all products are through strict test by our professional QC team before shipping.
Door to door service: We usually send the parcel by DHL, EMS and TNT etc. The tracking number will be sent to you after delivery. It usually takes 3--5 working days to reach from from our side to your side, which is very convenient for your business
OEM available
1. What detailed information do I need to provide if I want to place an order?
We need to know the following information: Capacity, Usage and other related parameters you need.
2. Do you have any discount?
Yes, if you buy large QTY, please send us a email, we will give you a big discount.
3. What terms of payment are available?
We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.
4.When will you arrange the production?
We will arrange the production immediately after receiving your payment.
5. How do you ensure good product quality?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.
